*Note Crate, Palletizing & Packaging of the door is applied at checkout*
Atlas Series Heavy Duty Vault Doors
4-Way 22-Bolt Locking System Vault Doors
Atlas Vault Doors come standard with a list of security & safety features most other vault door manufacturers only wish they could match. The Atlas door features a ½” solid steel front plate in the 2” step system door which is hand fitted to a ¼” solid steel frame, 4-Way – 22 bolt locking system and internal release. 3/4″ 60+ Rockwell Hard plate protects your S&G Spy-Proof Lock with Locking Dial from drill attacks. A 3 + 1 Titan Multi Re-locker system backs up your lock from punch attacks. 2300° Ceramic Fire Blanket provides beyond 2 hour fire protection. Choose from our popular standard colors or create your own custom door with gloss paint and custom finishes & hand pinstripes.
Atlas Series Standard Features
- 1/2″ Solid Steel Front Plate
- 2″ Step-System Door – Overall Door Thickness 6¼”
- 2 Hour Fire Door – 2300° Ceramic Fire Blanket
- 1/4″ Solid Steel Frame
- NEW! 4-Way 22-Bolt Locking System
- 4″ x 1½” Fully Rotating Locking Bolts
- Sargent & Greenleaf, U.L. Listed Group 2, Spy-Proof Lock with Locking Dial (Digital Lock Available)
- Adjustable Ball Bearing Hinges
- 3/4″ 60+ Rockwell Hard plate
- Internal Release
- Carpeted Door Panel
- Titan Multi Re-locker (Includes 1ea. Brass Arm & 4ea. Titan)
- Standard Texture Colors: Black, Wimbledon White, Brown, Gray, Dark Green and Burgundy – Gloss and Custom Finishes Available
- Choice of Silver, Gold or Black Matching Hardware
Atlas Series Vault Door Specifications
- Door: 2″ Step System Door with 1/2″ Solid Steel Front Plate
- Frame Thickness: 1/4″ Solid Steel
- Fire Rating: 2 Hour – 2300° Ceramic Fire Blanket and multi-layer fire board
- Locking Bolt System – 4-Way – Fully Active
- Number of Locking Bolts: 22 – 4″ x 1½” Locking Bolts Fully Active Bolts, 18 – Fully Rotating
- Lock Type: U.L. Listed Group 2, Sargent & Greenleaf, Spy-Proof Lock
- Hard Plate: 3/4″ Solid 60+ Rockwell Hard Plate
- Internal Release: Yes
- Re-Locker: Titan Multi Re-locker (Includes 1ea. Brass Arm & 4ea. Titan)
- Standard Finish: Black, Wimbledon White, Gray, Brown or Dark Green Matte Finish
- Gloss and Custom Finish Available: Yes
- Hardware: Choice of Silver, Gold or Black Matching Hardware
- Warranty: Limited Lifetime
IN-SWING HINGING OPTION (Any Door – Adds up to 200 lbs.) ADD $400 In-Swing frame depth must be 6½” or larger
Specifications
Specifications:
| 80″ x 30″ x 6″ to 10″ (frame depth) | 1065 lbs. |
| 80″ x 35″ x 6″ to 10″ (frame depth) | 1375 lbs. |
| 80″ x 40″ x 6″ to 12″ (frame depth) | 1775 lbs. |
| 80″ x 45″ x 6″ to 12″ (frame depth) | 2195 lbs. |
| In-Swing Hinging | Adds up to 200 lbs. |
Rough Opening:
Add 1/4″ to the Height of the Door and 1/2″ to the Width of the Door
Clear Thru Space | ||||
| 80″ x 30″ Clear Thru Space | —- | Out Swing | —- | 25″ |
| 80″ x 30″ Clear Thru Space | —- | In Swing | —- | 23″ |
| 80″ x 35″ Clear Thru Space | —- | Out Swing | —- | 30″ |
| 80″ x 35″ Clear Thru Space | —- | In Swing | —- | 28″ |
| 80″ x 40″ Clear Thru Space | —- | Out Swing | —- | 35″ |
| 80″ x 40″ Clear Thru Space | —- | In Swing | —- | 33″ |
| 80″ x 45″ Clear Thru Space | —- | Out Swing | —- | 40″ |
| 80″ x 45″ Clear Thru Space | —- | In Swing | —- | 38″ |
Specification/Installation Instructions Below, click to download
Additional Information
Warranty:
Fire – If your Vault Pro, Inc. safe or vault door is damaged during a fire, Vault Pro, Inc. will replace your safe for Free.
Break-In – If your Vault Pro, Inc. safe of vault door is attacked and force entered they will either repair or replace it for free.
Manufacturer Defect – In most cases, Vault Pro, Inc. will repair your safe or vault door on site due to manufacturer defect.
Extended Life Time Warranties
- Lifetime Lock and Attempted Break-In are not standard warranties. Locks are warranted by the manufacturer for a period of one year from date of purchase. Extended life time warranties on locks and Attempted Break-in Warranties are available at time of purchase or within 30 days of purchase.
- Vault Pro, Inc. does not cover the contents of safes or vaults, or the installation/removal of safes or vault doors for any reason under any circumstances.
- A police/fire report will need to be properly filed and provided to Vault Pro along with proof of purchase and owners identification in order to activate any fire or break-in warranty. In some cases Vault Pro will require your safe or vault door to be returned for proper inspection and repair/replacement. Vault Pro will guarantee return shipping on any product properly sent for repair or replacement.
